FAW 6x2 15 Ton Payload Dosing Tanker Serving Plant and Effluent Works
-
When You'll Get It:Jan 06 - Jan 10
-
Shipping & Support: In-stock items ship in 24 hours; custom orders ship per contract.
Each litre of product a factory buys is carried twice - once to the site, once around it - and the vehicle doing the site legs earns its money on turnaround rather than road speed. Tare on this 6x2 FAW is 10,000 kg, leaving a 15-tonne payload allowance on a 25,000 kg plated weight, which holds cost per tonne down and the filework light. Twin steering bogies afford it the manners to enter congested dosing points and reverse up delivery ramps that longer outfits block.
Technical Specifications
- Curb Weight(Kg)
- 10000
- Boundary Dimension(mm)
- 9000×2550×3550
- Tank Volume(m³)
- 14
- Tank Material
- Q235 Carbon Steel
- Mouth of tank
- One/Tow
- Discharge Opening
- Lined With Four-Fluorine Ball Valve
- Maximum Speed（km/h）
- 80
- Trade Name
- Jie Fang
- Engine Power（KW）
- Da Chai 164
- Front Axle/Rear Axle（t）
- 5/5/11
- Gearbox
- 9 Speed Manual Transmission
- Number of Axles
- 3
- Wheelbase (mm)
- 1900+4000
- Emission standard
- Euro 3-6
- Steering
- LHD/RHD
Standard Components Details
Vacuum pressure reducing valve
Discharge valve
Discharge box fire extinguisher
Anti-Corrosion Tank Body
Tank lining plastic process
Bottom emergency shut-off valve
Application Scenarios
Chemical Liquid Tank Truck Application scenarios
Our Chemical Liquid Tank Truck Widely used in chemical, petroleum, pharmaceutical, coating, environmental protection and other industries, suitable for:
Transportation of corrosive liquids such as strong acid, strong alkali and salts
Transportation of flammable and explosive media such as organic solvents, oils and resins
Transportation of non-hazardous liquids such as food-grade liquids, water purifiers and water reducers
Medium and long-distance transportation in industrial parks, ports, chemical plants, logistics centers, etc.
Factory Display
Where winters bite or summers bake, the make-up can be adjusted: a stainless cylinder, a suction unit for emptying, bulkheads splitting the compartment for two products, or EU-pattern manways with quick-closing valves. Tell us the chemicals, their concentrations and the routes they travel; the barrier system, seal materials and certificates are settled prior to fabrication.
Packing and Delivery
*Packing--Waxed or nude, covered with tarpaulin. *Shipping--Small units ship in 20GP, 40GP or 40HQ containers; larger units ship break-bulk, by bulk carrier or Ro-Ro, or as you require.
1.Q:Are you a factory or a trade company?
A: We are a leading manufacture of pressure vessels,bobtails,trailers, trucks, and skid mounted stations,and spare parts. Welcome to visit us in Suizhou city, the production base of Chinese special purpose vehicles.
2. Q: Where is your factory located?
A: We are located in Suizhou City,Hubei Province,China
3.Q:How can i visit there?
A:Welcome to the factory for inspection. You can fly to Wuhan Tianhe Airport, and our company will arrange a special car to pick you up.
4.Could you customize exactly according to my requirements?
A:Yes. We have professional R&D team, we can produce the product exactly according to your requirements.
5.Q: Do you provide certification that we need?
A:We can provide various certifications associate. Such as BV,DOT, ADR, SASO and so on.
6.Q: what's your payment terms?
A:T/T& L/C are preferred.
7.Q:Do you arrange shipment for the vehicles?
A:Yes,we can arrange shippment based on trade terms.
8. Q:What service can I get from you?
A:We provide lifelong tracking service and one year free warranty for all of our products. Meanwhile we provide free training and technical support to guide you repair your product. If need, we will also send original spare parts free of charge by air.
9.Q:How is the packing?
A:All the packing comply with exporting standard.
10.Q:How long is the lead time?
A:20-25 working days.
For other questiones,we will reply you ASAP after receiving your consult!
